Basic parameters

• Length*Width*Height (mm)

  10900*2550*3285

• Wheelbase (mm)

  5500

• Tire

  Front: 355/50R22.5; rear: 275/70R22.5

• Max speed (km/h)

  80

• Max number of seats

  25+2

• Max passenger capacity

  55

• Max manufacturer's total mass (kg)

  20600

• Front/rear axle (kg)

  8000/12600

• Floor type

  Low entry

New energy power system

• Battery (kWh)

  352.08

• Rated power 1(kW)

  120

• Rated power 2(kW)

  —

• Max gradeability 1

  15% (15km/h, 20s)

• Max gradeability 2

  —

• Single plug

  ●

• Dual-plug

  ○

• Charging power (150kW)

  ●

• Charging power (300kW)

  ○

• Emergency Assist for Pedal Misapplication (EAPM)

  ●

Seat

• Passenger seat model

  CS001

• Driver seat

  ● Three-point air suspended seat
  ○ NTS6860/875

• Wheelchair area

  1

Interior

• Driver zone enclosure

  ● Guardrail baffle
  ○ Driver enclosure

• Wheelchair lift

  —

• Wheelchair ramp

  ●

• Roof hatch

  —

Exterior

• Passenger door

  2-1

• Side window glass

  Fully-enclosed

• Insulated side window glass

  —

• Manual driver window

  ●

• Electric driver window

  —

• Front windshield

  Ordinary laminated glass

A/C

• Heating and cooling A/C

  ●

• Cooling/heating defroster

  ●

Chassis

• Front axle

  ZF RL82EC

• Drive axle

  ZF AV133

• Third axle

  —

• Air suspension

  ●

• ECAS

  ●

• Steering wheel

  RHD

• EPB

  ●

Safety and driving assistance system

• Electronic Braking System (EBS)

  ●

• Electronic Stability Control (ESC) System

  ●

• Advanced Emergency Braking System (AEBS)

  —

• Lane Departure Warning (LDW) System

  —

• Intelligent Speed Assist (ISA)

  —

• Collision warning system

  ○

• Reversing radar

  ●

Audio-visual entertainment and lighting

• Adjustable dashboard

  ●

• LED headlamp

  ●
